LiFePO4 Battery BMS PCB Protection 4S 12V 350A Li Ion Battery BMS 3.2V For EV Ebike Scooter

LiFePO4 Battery BMS PCB Protection 4S 12V 350A Li Ion Battery BMS 3.2V For EV Ebike Scooter
LiFePO4 Battery BMS PCB Protection 4S 12V 350A Li Ion Battery BMS 3.2V For EV Ebike Scooter LiFePO4 Battery BMS PCB Protection 4S 12V 350A Li Ion Battery BMS 3.2V For EV Ebike Scooter LiFePO4 Battery BMS PCB Protection 4S 12V 350A Li Ion Battery BMS 3.2V For EV Ebike Scooter LiFePO4 Battery BMS PCB Protection 4S 12V 350A Li Ion Battery BMS 3.2V For EV Ebike Scooter LiFePO4 Battery BMS PCB Protection 4S 12V 350A Li Ion Battery BMS 3.2V For EV Ebike Scooter LiFePO4 Battery BMS PCB Protection 4S 12V 350A Li Ion Battery BMS 3.2V For EV Ebike Scooter

Large Image :  LiFePO4 Battery BMS PCB Protection 4S 12V 350A Li Ion Battery BMS 3.2V For EV Ebike Scooter

Product Details:
Place of Origin: China
Brand Name: Passional
Model Number: 16S48V100A
Payment & Shipping Terms:
Minimum Order Quantity: 2-99 Pieces
Price: Negotiable
Contact Now

LiFePO4 Battery BMS PCB Protection 4S 12V 350A Li Ion Battery BMS 3.2V For EV Ebike Scooter

Description
Keywords: LiFePO4 Battery BMS Base Material: FR-FOUR
Copper Thickness: 1/2oz 1oz 2oz 3oz Min. Line Spacing: 0.065mm
Application: Battery Packs For Energy Storage Communication: No
Size: 200MM*134MM*19MM Weight: About 690g
High Light:

Li Ion Battery BMS 0.065mm

,

3OZ Li Ion Battery BMS

,

LiFePO4 Battery BMS 2OZ

LiFePO4 Battery BMS PCB Protection 4S 12V 350A Li Ion Battery BMS 3.2V For EV Ebike Scooter

LiFePO4 Battery BMS Description:
The lithium iron phosphate battery is a lithium-ion battery using lithium iron phosphate (LiFePO4) as the positive electrode material and carbon as the negative electrode material.
LiFePO4 batteries have the advantages of high working voltage, high energy density, long cycle life, good safety performance, low self-discharge rate and no memory effect.



Why we need the BMS board for the battery ?
1.Battery protection board, as the name implies, lithium battery protection board is mainly an integrated circuit board that protects rechargeable (usually lithium batteries).
2.The reason why lithium battery (rechargeable type) needs protection is
3.determined by its own characteristics. Because the material of the lithium battery itself determines that it cannot be
4.overcharged, over-discharged, over-current, short-circuited, and ultra-high temperature charging and discharging,
The three basic functions of the lithium battery protection board are
short-circuit protection, Overcharge protection and over-discharge protection.
Everyone can understand the significance of the BMS board to the lithium battery.
LiFePO4 Battery BMS PCB Protection 4S 12V 350A Li Ion Battery BMS 3.2V For EV Ebike Scooter 0

Product Description


Content
Specification
Unit
Remark
Discharge
Continuous Discharge current
350
A

Pluse Discharge Current
1000±50
A

Charge
Charge cut-off voltage
14.8
V

Max charge current
200(MAX)
A

Over Charge protection
Overcharge detection voltage
3.75±0.05
V

Overcharge detection delay time
1000±200
MS

Overcharge release voltage
3.55±0.05
V

Balance Portection
Balance Detection voltage
3.5
V

Balance release detection voltage
3.5
V

Balance current
40±0.05
mA

Overdischarge Portection
Overdischarge detection voltage
2.2±0.05
V

Overdischarge detection delay time
1000±200
MS

Overdischarge release voltage
2.7±0.05
V

Overcurrent Portection




Overcurrent protection current
1000±50
A

Overcurrent detection delay time
600±300
MS
can set as per your request
Release condition
Cut short load


Short Protection
Detection condition
Out load short cycles


Detection delay time
500±150
uS

Release condition
Cut load


MOS Temp. protection
Over Charge protection temp.
85
℃
can set as per your request
Over Disharge protection temp.
85
℃

Battery high temperature protection
Charging protection temp.
55
℃

Discharging protection temp.
75
℃

Battery low temperature protection
Charging protection temp.
-20
℃

Discharging protection temp.
-40
℃

Interior resistance
Main loop electrify resistance
≤30
mΩ

Current consumption
Current consume in normal operation
≤100
uA


Sleep current(over discharge)
≤20
uA

Working Temp.
Temp.range
-20/+50
℃



LiFePO4 Battery BMS PCB Protection 4S 12V 350A Li Ion Battery BMS 3.2V For EV Ebike Scooter 1 LiFePO4 Battery BMS PCB Protection 4S 12V 350A Li Ion Battery BMS 3.2V For EV Ebike Scooter 2



Product Usage

LiFePO4 Battery BMS PCB Protection 4S 12V 350A Li Ion Battery BMS 3.2V For EV Ebike Scooter 3
Our Services:

1. We offer We provide customers with one-stop procurement services.
2. Here you can find all the main accessories related to lithium batteries.
3. Save time and energy for customers.


How to choose the right BMS board?
1. Determine your battery type (ternary/NCM, iron lithium/LFP, lithium titanate/LTO) and determine the number of strings and
parallels of the battery pack. Choose according to the number of series

2. Determine whether the battery pack is charged and discharged in the same port or in separate ports.
The same port is the same line for charging and discharging, But the separate port one is for
charging and discharging thought independent lines

3. Determine the current value required by the protection board: I=P/U. That is,current=power/voltage. .
Remember this is only a theoretical value. In reality. We use this theoretical value as a reference.
Taking into account the load, the uphill and the environment just started,Generally the two-wheel electric vehicles choose more
than 2 times this theoretical value. Three-wheeled electric vehicles choose more than 3 times this theoretical value. Four-wheel
low-speed vehicles generally have about 3.5 times. For inverters and energy storage products, 1.2 times is enough.
Or refer to the current limit of the electric vehicle controller. Guarantee. The current value of the guard plate must be greater
than the control current limit value.
